DUPERTHAL UNDER-BENCH CHEMICAL WASTE SAFETY CABINET TYPE 90

DUPERTHAL UNDER-BENCH CHEMICAL WASTE SAFETY CABINET TYPE 90

GENEL BİLGİLER

  • Provides maximum safety with 90 minute fire resistance according to the EN 14 470-1 standard.
  • TÜV certified according to DIN EN 14 727 (laboratory furniture standard).
  • Guaranteed user friendliness and long service life with TÜV “High Quality” quality certificate.
  • Ease of use with push-to-open door.
  • One automatic drawer, two 10 l PE waste drums and connection pieces are standard.
  • The automatic drawer is easy to use and is pulled back automatically in case of fire.
  • Capacity gauge allows monitoring the air suction rate and the capacity of the waste drums.
  • Capped funnels or direct connection pieces for devices such as HPLCs can be mounted on the cabinet for chemical waste discharge.
  • The cabinet and the waste drums are grounded according to the TRGS 727 standard.
  • Doors close automatically in case of fire.
  • Ergonomic lock system at the handle level.
  • The cabinet can be leveled easily with adjustable feet.
  • European Union GS, CE approved.

TEKNİK BİLGİLER

  DISPOSAL UTS  ergo S 2

Details 1 drawer, 1 drum mount, 2x10 l conductive PE drum
1 capacity gauge, valve and waste lid with exhaust tube,
1.5 m PTFE hose with electrical conductor, 1 air flow rate and
capacity gauge screen, 1 ratchet grounding cable and plinth
Dimensions
External [mm]
(width x depth x height)
600 x 593 x 631
Internal [mm]
(width x depth x height)
503 x 463 x 480
Weight [kg] 130
Storage capacity / surface area approx.
[10 l / 2,64 gal] PE drums (conductive)

ÜRÜN FOTOĞRAFLARI
